| Part Number | SF63800ZZ |
| System of Measurement | Metric |
| Bearing Type | Ball |
| Ball Bearing Type | Flanged |
| For Load Direction | Radial |
| Construction | Single Row |
| Inner Ring Type | Standard |
| Seal Type | Shielded |
| Bore Dia | 10 mm |
| Bore Dia Tolerance | -0.008mm to 0 |
| Outer Dia | 19 mm |
| Outer Dia Tolerance | -0.008mm to 0 |
| Width | 7 mm |
| Width Tolerance | -0.12mm to 0 |
| Flange Outer Dia | 21 mm |
| Flange Thickness | 1.5 mm |
| Ring Material | 440C Stainless Steel |
| Ball Material | 52100 Chrome steel |
| Cage Material | 300 Series Stainless Steel |
| Shield Material | 300 Series Stainless Steel |
| Dynamic Radial Load | 348 lbf |
| Static Radial Load | 170 lbf |
| Max Speed (X1000 rpm) | 30.6 |
| Lubrication | Required |
| Shaft Mount Type | Press Fit |
| Temperature Range | -30° to 110°C |
| ABEC Rating | ABEC-1 |
| Radial Clearance Trade No. | C0 |
| Radial Clearance | 0.002mm to 0.013mm |
| RoHS | Compliant |
| Ball Qty | 10 |
| Ball Size | 2.381 mm |
| Weight | 7.80 g |
SF63800ZZ Large Size Flanged Ball Bearings have a lip extension on the outer ring. SF63800ZZ bore dia is 10 mm. Its out dia is 19 mm. SF63800ZZ ball material is 52100 Chrome steel. Its seal type is Shielded. The SF63800ZZ Large Size Flanged Ball Bearings can bear heavy radial loads and moderate thrust loads in both directions.
Food Processing Machinery, Conveyors, Material Handling, Belt Drives in HVAC, Textile Machines, Baggage Systems, Medical Processing, Scanner Motors, Stepping Motors, Rotary Encoders, Card Readers, etc.
Several factors must be considered for choosing Large Size Flanged Ball Bearings. These factors include the ring material, design, shields and seals, cage, Annual Bearing Engineering Committee (ABEC) grade, Seals and shields are used in miniature bearings (specifically ball bearings) to retain lubricants and prevent particulate contamination from reaching critical surfaces. Seals are used where minimal light contact is offered. Seals for miniature bearings provide deterrence to particulate contamination, but increase torque and limit operating speeds. Shields are used in most applications.
