BT4B 328817 EX1/C475

Product Attributes

Part Number	BT4B 328817 EX1/C475
Type	Bearing
System of Measurement	Metric
Bearing Type	Roller
Roller Bearing Type	Tapered Roller
For Load Direction	Combined Radial and Thrust
Construction	Four-row
Seal Type	Open
Bore Dia	343.052 mm
Bore Dia Tolerance	-0.04mm to 0
Outer Dia	457.098 mm
Outer Dia Tolerance	-0.045mm to 0
Total Bearing Width Over Inner Rings	254 mm
Total Bearing Width Over Inner Rings Tolerance	-0.25mm to 0
Total Bearing Width Over Outer Rings	254 mm
Total Bearing Width Over Outer Rings Tolerance	+0.4mm to -0.4mm
Abutment Diameter Shaft	362 mm
Abutment Diameter Housing	362 mm
Chamfer Dimension Inner Ring	min.1.0 mm
Ring Material	52100 Chrome Steel
Roller Material	52100 Chrome Steel
Cage Material	Steel
Dynamic Radial Load	697500 lbf
Static Radial Load	1440000 lbf
Lubrication	Required
Temperature Range	-30° to 110 °C
ABEC Rating	ABEC-1
Radial Clearance	Standard (Available in C3/C4/C5)
RoHS	Compliant
REACH	Compliant
Weight	242.51 lb
